BOLT The Bolt™ High-Speed Camera Robot is the fastest of its kind – capturing images in crisp focus that would be impossible by hand or any other method. The precision cinema robot adds an entirely new perspective to filming – whether shooting commercials, tabletop work, film or television.
Rental Rates
One Day (Mon-Sun) : $4850 + HST
10' Track lengths: $500/each
Delivery fee within ACCP Boundary: $900
Requires Operator + Technician
For all information and inquiries please email rentals@2dhouse.com
Specifications
Operating Envelope
Max Height (from ground)
3.5m / 11'5"
Max Reach (from rotate centre)
2.0m / 6'6"
Rig Performance
Arm ARC Move
7 m/s max speed at camera
Arm with Track
12 m/s max speed at camera
Track
5 m/s max speed at camera
Rotate
-160° to +160° range of travel @ 240°/s
Lift
-40° to +210° range of travel @ 240°/s
Arm
-60° to +220° range of travel @ 300°/s
Pan
-265° to +265° range of travel @ 350°/s
Tilt
-210° to +10° range of travel @ 350°/s
Roll
-720° to +720° range of travel @ 870°/s
Practical Shooting Speeds
Vertical
1m (3'3") vertical movement / 0.5s
Horizontal
1m (3'3") horizontal movement / 0.5s
Arc
180° arc, 75cm radius / 1.5s — 180° arc, 45cm radius / 1s
Rig Weights
Bolt + Base
600kg / 1,323 lbs
Maximum Camera Payload
20kg / 44 lbs
Power Connection
Power Requirements
3x 400 volts, 32 amps, 50–60Hz
Generator
3k VA (Bolt) / 14k VA (Bolt on track)
